TOA P2240

TOA P2240 240W Power Amplifier, both 100V or line input, 100V, 70V & 4 Ohm outputs.

Original price was: $1,089.00.Current price is: $980.10.

In Stock
SKU: P2240 Categories: , Tag:

Description

TOA P2240 Power and Mixer Amplifiers are designed to be highly cost effective solutions to the demands of PA applications. They offer high levels of performance and versatility and are well-suited for paging and background music. Ideal for use in schools, offices, shops, warehouses, factories, houses of worship and large meeting places.

TOAs P2240 Power Amplifier is designed to complement the A2000 Series of Mixer Power Amplifiers and is consequently a highly cost effective solution to the demands of PA applications. Features such as front bass, treble and volume controls and a 100 volt line input enures its versatility and adaptability to situations where a booster amplifiers is needed. The 100 volt line input allows it to be added to the end of an existing 100 volt speaker line or used on the high impedance speaker output of a mixer amplifier.

The P-2240 offers a high performance-to-cost ratio, and can be used with TOA?s A-2000 Series mixer power amplifiers. Because the P-2240 features a 100V line input, it can be connected to the speaker line from another amplifier. Also, the P-2240?s power can be switched on and off by remote control, allowing it to be operated independently of the A-2000 Series.

Features

  • 240 watt 100 volt, 70 volt or low impedance outputs
  • Volume, bass and treble control on front panel
  • Line level in and out for cascade operation
  • 100 volt line input 50Hz or 20kHz frequency response
  • Rack mountable with MB25B brackets
  • 3 year warranty

Specifications

Power Source 220 – 240 V AC, or 24 – 30 V DC
Rated Output 240 W
Power Consumption 238 W (EN60065), 520 W (AC operation at rated output),
15 A (DC operation at rated output)
Frequency Response 50 Hz – 20 kHz (±3 dB)
Distortion 1 % or less at 1 kHz, 1/3 rated power
Input Line in: 0 dB*, 10 kΩ, balanced, screw terminal,
distance between barriers: 8.3 mm (0.33″)
Speaker line in: 40 dB*, 330 kΩ, unbalanced, screw terminal,
distance between barriers: 8.3 mm (0.33″)
Power remote control: Make contact

Downloads

a-2000 series_mixer amplifiers_brochure
