TOA A2060D

TOA A2060D 60W Class D Mixer Amplifier, 100V only output. 3x MIC, Mic 1 VOX, 2x line.

$459.00 $413.10

In Stock



SKU: A2060D Categories: , Tag:

Description

TOA A2060D Class D 60 watt Mixer Amplifier, 100V only output. 3x MIC, Mic 1 VOX, 2x line.

The TOA A2060D is a high performance mixer power amplifiers suited for broadcasting paging or background music in houses of worship, schools, offices, shops and factories. Equipped with balanced microphone inputs for better isolation from external noise, compared to unbalanced inputs, the A2060D is suitable for AC operation and comes with power outputs of 60W. It is finished with a scratch and fingerprint-resistant surface for easy handling as well as quick volume control with master volume knob.

For compatible rack mount kit please see TOA MB25B

Features

  • Class D with 60 Watts
  • 3 microphone inputs, 2 AUX input and 1 recording output
  • Speaker output of constant voltage distribution system (100 V)
  • Independent tone control of boost and cut type for both high and low frequency
  • MIC 1 with phantom power and mute function
  • Current limiter to prevent damage due to current overload
  • Excess heat limit to protect the transistor and power transformer
  • Finished with a scratch and fingerprint-resistant surface for easy handling

Use TOA MB25B (sold separately) for compatible rack mounting kit.

Note this is the new Class D model with the following differences over the analogue models:

  • VOX muting on mic 1
  • 100V line high impedance output only – no 4 or 8 ohm low impedance output
  • 240VAC operation only – no 24VDC option

Specifications

Power Source 220 – 240 V, 50/60Hz
Rated Output 60 W
Power Consumption 16 W (AC operation at 1/8 maximum output without clip)
Frequency Response 50 – 20,000 Hz, ±3 dB
Distortion Under 1% at 1 kHz, 1/3 rated power
Input MIC 1-3: -60 dB*, 600 Ω, balanced, 3P XLR
AUX 1-2: -20 dB*, 10 kΩ, unbalanced, RCA pin jack
Output Speaker out: Balanced (floating)
High impedance: 170 Ω (100 V)
Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack
Phantom Power DC +21 V (MIC 1)
S/N Ratio Over 60 dB
Tone Control Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Muting MIC 1: Mutes other input signals by 0-30 dB attenuation
Indicator Power LED, peak LED, signal LED
Finish Panel: ABS resin, black
Case: Steel plate, black
Dimensions 420 (W) × 100.6 (H) × 280.3 (D) mm (16.54″ × 3.96″ × 11.04″)
Weight 4.6 kg (10.14 lb)

Downloads

TOA_A2000d_and_A2000DT_Series_Digital_PA_Amplifiers-brochure
