QSC AC-S6T
QSC AC-S6T 6.5" 2-way Surface mount speaker 130? conical for use with 70 or 100V or 8-ohm systems inc yoke Black or White (Pair)
Regular price
$427.50
Regular price
$475.00
Sale price
$427.50
Unit price
per
inc. GST
Shipping calculated at checkout.
Product Enquiry Form
Delivery Charges
Freight Charges within Australia
Soundgear Australia will do their very best, to ensure your order arrives as quickly as possible. We use an integrated network of post and road companies like StarTrack, TNT, Go Logistics, and Australia Post to deliver Australia wide. We will do our best to ship as quick as possible.
Oversize Items:
- Oversize items or multiple items such as horns, speakers, sports packs, may also incur additional charges to those calculated at checkout. We will contact you with any additional charges.
GENERAL AUDIO (excludes Lecterns-see Lectern pricing below)
| Price Range | Cost | Method |
| Up to 25 | $15 | Express Post |
| $26 to $300 | $25 | Post / Road |
| $301 to $500 | $28 | Post / Road |
| $501 to $1000 | $30 | Post / Road |
| $1001 to $2500 | $45 |
Post / Road |
Oversize Items:
- Oversize items or multiple items such as horns, speakers, sports packs, may also incur additional charges to those calculated at checkout. We will contact you with any additional charges.
Freight charges to W.A /N.T/Far North QLD, Regional and Rural areas:
- Additional charges to those listed may apply.
- Please contact us for a quote.
- If you place an order and we can’t get it to you for the freight charged we will contact you and let you know of the additional charges.
Sending to Residential Addresses:
- For all residential deliveries an additional $27.50 Inc-GST may also be charged for certain brands (Mipro, Bosch, Earthworks, Alfatron, FBT, Antari).
- If we cannot express Post it and it needs to go with a courier service, the additional residential fee will apply.
- If you have placed an order online we will contact you if this additional charge applies. Please feel free to call us on 02 9585 8687 to check the freight charge.
Deliveries to residential address need an “ATL” (authority to leave goods)
- Please leave us a note at check out advising us of an “ATL” ie/porch, front door etc should you not be home to sign.
| Price Range | Cost | Method Delivery times |
| Zone A | $110 | Zone A Areas (Sydney, Melbourne, Canberra, Adelaide, Newcastle, Wollongong) |
| Zone B | $242 | Country /Regional-All states, Perth, QLD -(excluding TAS /N.T) |
| Zone C | Quote required for TAS /N.T | |
| Note: | Zone A only calculated at checkout. All other zones will need to be charged separately. We will contact you to arrange this. |
**WE DO NOT SHIP OVERSEAS**
Regular price
$427.50
Regular price
$475.00
Sale price
$427.50
This pair of black 6.5" QSC AcousticDesign Series AD-S6 is a surface mounted, 16 ohm, 6.5" passive two-way loudspeaker system ideally suited for a wide variety of foreground and background sound reinforcement applications, including restaurants, retail, audio/visual, education, concourses, casinos, transportation terminals, houses of worship, and large system ancillary support. Designed for integrators looking for a premium-quality installed sound solution where coverage, performance, and aesthetics are paramount. The speakers are easy to install and offer high weather resistance (IP44) for use outdoors.
A high quality 165 mm polypropylene cone transducer with butyl rubber surround and a 25 mm aluminium dome tweeter offers pristine clarity through the critical vocal range for increased speech intelligibility. With 130 degrees of conical coverage, the AC-S6T reduces the number of loudspeakers required for even coverage in close proximity. The UV treated high impact ABS enclosure and ported baffle assembly has been optimally tuned for added musicality, creating low frequency extension down to 60 Hz. To maintain this frequency response, the AC-S6T utilizes a 30-watt low-saturation and low-loss 70/100V transformer with varying selectable taps, including an 8? bypass.
SOLD IN PAIRS
A high quality 165 mm polypropylene cone transducer with butyl rubber surround and a 25 mm aluminium dome tweeter offers pristine clarity through the critical vocal range for increased speech intelligibility. With 130 degrees of conical coverage, the AC-S6T reduces the number of loudspeakers required for even coverage in close proximity. The UV treated high impact ABS enclosure and ported baffle assembly has been optimally tuned for added musicality, creating low frequency extension down to 60 Hz. To maintain this frequency response, the AC-S6T utilizes a 30-watt low-saturation and low-loss 70/100V transformer with varying selectable taps, including an 8? bypass.
SOLD IN PAIRS
- High quality transducers provide exceptional clarity through the critical voice range.
- Improved musicality often not seen in typical BGM class products.
- Ported baffle for increased low frequency extension down to 70 Hz.
- Low saturation 70/100V transformers with 8 ohm bypass.
- 4-pole Euroblock connector eases system wiring.
- Advanced voicing via QSC Intrinsic Correction™, applied using Q-SYS processing or CXD amplifier platforms.
- Available in black (RAL 9011) or white (RAL 9010).
- Complete EASE, CAD & BIM information available online.
| Specifications | AC-S6T |
| Effective frequency range1 | 60 Hz–20 kHz |
| Rated noise power / voltage2 | 30 watts / 15.5 volts rms |
| Broad-band sensitivity3 | 86 dB SPL |
| Coverage angle (-6 dB) | 130° conical (500 Hz–5 kHz) |
| Directivity factor (Q) | 6 |
| Directivity Index | 8 dB |
| Maximum continuous SPL4 | 101 dB |
| Maximum peak SPL4 | 107 dB |
| Rated impedance | 8 ohms |
| Recommended amplifier power | 60 watts into 8 ohms |
| Transformer taps | 70V: 30, 15, 7.5, 3.7, 1.9 watts 100V: 30, 15, 7.5, 3.8 watts 8 ohm bypass |
| LF transducer | 165 mm (6.5-inch) Polypropylene woofer with 25 mm (1-inch) voice coil |
| HF transducer | 25 mm (1-inch) Aluminium dome tweeter with 25 mm (1-inch) voice coil |
| Input connector type | Euroblock connector with parallel output |
| Enclosure material | UV treated, high impact ABS polymer |
| Grille material | Powder coated steel |
| Yoke material | Powder coated steel with brass inserts |
Enclosure Details
|
IP-44 Designed for indoor use -20 to 50° C (-4 to 122° F) |
| Product Dimensions (HWD) inches | 11.9 x 8.5 x 7.8 |
| Product Dimensions (HWD) mm | 303 × 215 × 197 |
| Net Weight | 8.3 lb / 3.8 kg |
| Shipping weight | 8.4 kg (18.6 lb) pair packed |
| Shipping Dimensions (HWD) inches | 14.1 × 10.5 × 18.5 pair packed |
| Shipping Dimensions (HWD) mm | 359 x 267 x 470 pair packed |
| Included accessories | Yoke mount system, euroblock connector |
