The MDA 4125 is a compact, 1U half-rack and energy-efficient 4-channel Class D amplifier, ideal for low-to-medium power installations.
It delivers 4 channels x 125W at 4 Ω in LO-Z mode or 2 channels x 250W at 100V in HI-Z mode.
This amplifier has Power Sharing mode. With a built-in DSP accessible via a web browser, integrated WiFi, S/PDIF I/O, and GPIO, this unit ensures flexible system control and straightforward setup using preloaded FBT speaker presets.
The 4125D comes with an integrated 4in-4out Dante card for digital audio streaming.
Highly reliable 4-channel class D power amplifier
Flexible Hi-Z and Lo-Z speaker output configuration
In/Out S/PDIF features facilitates easy system extension
Remote control through integrated WiFi access point or Ethernet port
Intuitive browser-based user interface offering full control
Speaker preset libraries reduce system setup time
8-pin GPIO interface adds standard remote control features
- Channels: 4 x Lo-Z / 2 x Hi-Z
- Output Power Lo-Z (single channels driven/Ch 1 + Ch3): 2 x 250W @ 4 Ohm (Power Share), 2 x 250W @ 8 Ohm (Power Share)
- Output Power Lo-Z (all channels driven): 4 x 125W @ 4 Ohm, 4 x 125W @ 8 Ohm
- Output Power Hi-Z (all channels driven): 2 x 250W @ 70V, 2 x 250W @ 100V
- Total System Power: 500W
- Output Voltage: 70V/140V (unloaded), Bridged 140V/280V (unloaded)
- Amplifier Topology: Class D PWM modulator with ultra-low distortion
- S/N Ratio: >106dB (A-weighted, 20Hz-20kHz, 8Ohm load)
- THD+N (typical): < 0.05% (20Hz-20kHz, 8Ohm load 3dB below rated power)
- Frequency Response: 20Hz-20kHz +0/-0.25dB (8Ohm load, 3dB below rated power)
Electrical
- Protection Circuits: Short circuit protection, DC protection, Under voltage protection, Temperature protection, Overload protection
- Cooling: Dynamically controlled force cooling
- Power Supply: Universal mains switch mode power supply with Power Factor Correction (PFC) and standby converter
- Operating Voltage: Universal Mains, 100V-240V, 50Hz-60Hz
- Power Consumption: 150W
- Standby Consumption: <0.5 W
- Operating Temperature: 32F to 104F
Physical
- Dimensions: 12.59 x 8.66 x 1.73 inches
- Weight: 6.17 lbs
