Sale!

TOA A2060

TOA A2060 60W Mixer Amplifier, 100V. 3x MIC inputs, 2x line. 70V & 4 Ohm outputs.

$458.10

In Stock
SKU: A2060 Categories: , Tag:

Description

TOA A2060 Mixer and Power Amplifiers is designed to be highly cost effective solution to the demands of PA applications. With high levels of performance and versatility it is well-suited for paging and background music. Ideal in schools, offices, shops, warehouses, factories, houses of worship and large meeting spaces.

Note: TOA A2060 is an analogue model with the following differences;

  • Contact closure muting on mic 1
  • High (70/100V line) and low impedance (4 Ohm) outputs
  • 24VDC operation as well as 240VAC

The TOA A-2000 series makes available a wide range of power outputs (A-2060: 60W, A-2120: 120W), with a frequency response of 50 – 20,000 Hz and distortion under 1%. Three balanced/phone jack MIC inputs and two unbalanced/RCA pin jack AUX inputs, along with high and low impedance balanced (floating) speaker outputs and unbalanced REC outputs ensure operational versatility. Phantom power and muting are available on MIC 1, along with tone control for bass and treble. Power, signal and peak indicators are provided. In addition, the P-2240 Booster Amplifier offers a means of increasing power amplification for system expansion through adding more speakers.

Features

  • 60W single zone mixer amplifier (analogue model)
  • 5 inputs; 3 mic (XLR) and 2 line level (RCA)
  • Contact closure muting on mic 1
  • High and low impedance output
  • 24VDC or 240VAC operation
  • Use optional MB25B brackets for rackmounting
  • Manufacturers Warranty of 3 Years

Specifications

Power Source 220 – 240V AC or 24V DC
Rated Output 60W
Power Consumption 72W (EN60065), 150W(AC operation at rated output, 4A (DC operation at rated output)
Frequency Response 50 – 20,000Hz (+/- 3 dB)
Distortion Under 1% at 1kHz,1/3 rated power
Input MIC 1-3: -60db 600Ω,electronically balanced, XLR-3-31 type. AUX 1,2: -20dB, 10kΩ, unblanced, RCA pin jack. Mute: screw terminal (for MIC 1)
Output SPEAKER OUT:Balanced (floating)
HIGH IMPEDANCE:170Ω (100V)
LOW IMPEDANCE: 4Ω (15.5V)
REC. OUT: Odb, 600Ω unbalanced, RCA pin jack
Phnatom Powe DC + 21V (MIC 1)
S/N Ratio Over 60dB
Tone Control Bass: +/- 10 dB at 100k Hz Treble: +/- 10 dB at 10k Hz
Muting Contact closure: Mutes other signals by 0 – 30 dB attenuation
Indicator Power signal, peak
Finish Panel: ABS resin, black/Case: Steel plate, black
Dimensions 420 (W) x 100.9 (H) x 280.2 (D) mm
Weight 7kg

Downloads

a-2000 series_mixer amplifiers_brochure
