Tascam CD200BT
Professional CD Player with Bluetooth Receiver.
Product Enquiry Form
Delivery Charges
Freight Charges within Australia
Soundgear Australia will do their very best, to ensure your order arrives as quickly as possible. We use an integrated network of post and road companies like StarTrack, TNT, Go Logistics, and Australia Post to deliver Australia wide. We will do our best to ship as quick as possible.
Oversize Items:
- Oversize items or multiple items such as horns, speakers, sports packs, may also incur additional charges to those calculated at checkout. We will contact you with any additional charges.
GENERAL AUDIO (excludes Lecterns-see Lectern pricing below)
| Price Range | Cost | Method |
| Up to 25 | $15 | Express Post |
| $26 to $300 | $30 | Express Post / Post / Road |
| $301 to $500 | $35 | Express Post / Post / Road |
| $501 to $1000 | $40 | Express Post / Post / Road |
| $1001 to $2500 | $45 |
Express Post / Post / Road |
Oversize Items:
- Oversize items or multiple items such as horns, speakers, sports packs, may also incur additional charges to those calculated at checkout. We will contact you with any additional charges.
Freight charges to W.A /N.T/Far North QLD, TAS, Regional and Rural areas:
- Additional charges to those listed may apply.
- Please contact us for a quote.
- If you place an order and we can’t get it to you for the freight charged we will contact you and let you know of the additional charges.
Sending to Residential Addresses:
- For all residential deliveries an additional $15.00 Inc-GST may also be charged for certain brands (Mipro, Bosch, Earthworks, Alfatron, FBT, Antari).
- If we cannot express Post it and it needs to go with a courier service, the additional residential fee will apply.
- If you have placed an order online we will contact you if this additional charge applies. Please feel free to call us on 02 9585 8687 to check the freight charge.
Deliveries to residential address need an “ATL” (authority to leave goods)
- Please leave us a note at check out advising us of an “ATL” ie/porch, front door etc should you not be home to sign.
LECTERNS
All lectern freight charges will need to be quoted. Our regular freight charges online will not apply.
**WE DO NOT SHIP OVERSEAS**
Stream Music Wirelessly from Bluetooth® Devices
With a front-panel-mounted antenna for maximum wireless reliability, the CD-200BT supports audio file playback from a variety of Bluetooth® compatible devices. And virtually any audio file type is supported — if your Bluetooth® device can play the file back by iTunes, Windows Media Player, or other player apps, it can be streamed wirelessly to the CD-200BT. With no additional wires needed to stream music from compatible audio sources, the CD-200BT allows for fast and easy audio playback.
Note: The transmitting device must support Bluetooth® transmission.
Register Bluetooth® Devices in Advance for Faster Source Switching and Operation
Bluetooth® audio playback requires pairing a transmitter to your receiver. Normally, only one Bluetooth® device and be paired at a time, but the CD-200BT’s device selection function allows you to pair multiple transmitting devices. By pairing in advance, you can switch seamlessly between different Bluetooth® transmission devices for playback with minimal connectivity interruption (only one device can be used for playback at a time). You can check the connection status of your transmitting devices directly from the CD-200BT for faster troubleshooting and easier system management.
High Quality Wireless Audio Playback with aptX® Codec
The CD-200BT supports multiple Bluetooth® transmission codecs to ensure high-quality audio playback from any transmitting device. The CD-200BT supports the A2DP (Advanced Audio Distribution Profile) for high-quality music playback, and SBC (Sub Band Codec), a standard A2DP codec. In addition, it supports the aptX® codec, making high quality wireless audio playback possible. The aptX® codec also has an error recovery function, so your audio is much less likely to be interrupted compared to ordinary SBC transmission.
High-Quality CD Drive
All models in the CD-200 series have the same highly-regarded and reliable CD drive. We have achieved higher dependability, quality and reputation.
Comprehensive Audio Format Support, with 10-second Skip Prevention
The CD-200BT is perfect for any install application where audio format versatility is needed, with CD- drive support for CD-DA, WAV, MP3, and MP2 audio files (wireless Bluetooth® playback supports any file type your transmitting device can play). The 10-second shockproof memory prevents skipping caused by excessive bass, unexpected bumps and jolts, and other causes. Data stored in the CD-200BT's memory can be played back without skipping, helping you avoid distracting playback interruptions.
- SD card / USB flash drive player (supports WAV, MP3, AAC)
- USB DAC (Digital Audio Converter)
- DAB/FM tuner
- Bluetooth audio supported as an option*
- Balanced XLR and unbalanced RCA outputs
- Auto cue and auto ready functions
- Pitch control function (+/-16%)
- Q-SYS platform compatibility allowing full playback control (Under development) **
- Power-on-play function can automatically start playback when the unit is turned on
- Incremental playback function jumps to the beginning of the next track
- Key original function changes playback speed without changing pitch
- Fade-in / fade-out playback function
- Repeat function including A-B repeat/all/single playback
- Direct track searching using the unit's number keys
- Wireless control using the free iOS/Android TASCAM MEDIA CONTROL CENTER app*
- Use of the optional remote control RC-20 allows direct playback start of up to 20 tracks
- External control via Ethernet (Telnet) supported as an option**
- Fader start / stop and tally output are possible using the CONTROL I / O connectors
- Unbalanced RCA connectors dedicated for tuner output
- Level adjustment function for each output
- Panel lock function can disable use of front panel buttons to increase operation confidence
- Headphone output enables audio monitoring
- 1U rackmount size
* A Bluetooth adapter (AK-BT2) is required.
** An Ethernet control card (IF-E100) is required.
Spec Description
| Supported media | SD cards (512 MB - 2 GB), SDHC cards (4 GB - 32 GB), SDXC cards (64 GB - 512 GB), USB flash drives (512 MB - 512 GB) |
| File System | FAT16, FAT32, exFAT |
| Playback file formats | |
| WAV | 44.1k/48k Hz, 16/24-bit (LPCM) |
| MP3 | 44.1k/48k Hz, 32/64/96/128/192/256/320 kbps, VBR |
| AAC | 44.1k/48kHz, 32-320 kbps, VBR (MPEG4 AAC-LC (audio stream), DRM not supported) |
| Maximum file size | 4GB |
| Maximum number of files | 999 (including folders) |
| Maximum number of folder levels | 16 (The full path, including the file name, must not exceed 260 characters.) |
| Number of channels | 2 channels (stereo) 1 channel (mono) |
| Analog audio output ratings | |
| ANALOG OUTPUT (BALANCED) | |
| Connectors | XLR-3-32 (1: GND, 2: HOT, 3: COLD) |
| Rated output level | +4 dBu (1.23 Vrms, when analog output level setting OFF) |
| Maximum output level (switchable) | +20 dBu (7.75 Vrms, when analog output level setting OFF) |
| Output impedance | 100Ω |
| ANALOG OUTPUT (UNBALANCED) | |
| Connectors | RCA pin jacks |
| Rated output level | -10 dBV (0.316 Vrms, when analog output level setting OFF) |
| Maximum output level (switchable) | +6 dBV (2.0 Vrms, when analog output level setting OFF) |
| Output impedance | 210Ω |
| TUNER OUTPUT (UNBALANCED) | |
| Connectors | RCA pin jacks |
| Rated output level | -10 dBV (0.316 Vrms, when -16 dBFS DAC output and tuner output level setting OFF) |
| Maximum output level (switchable) | +6 dBV (2.0 Vrms, when 0 dBFS DAC output and tuner output level setting OFF) |
| Output impedance | 210Ω |
| PHONES | |
| Connector | 6.3 mm (1/4") standard stereo jack |
| Maximum output level | 20 mW + 20 mW or higher (THD+N 0.1% or less, into 32 Ω load) |
| Control input/output | |
| REMOTE | |
| Connector | 2.5 mm TRS jack (Tip: Signal 1, Ring: Signal 2, Sleeve: GND) |
| CONTROL IN/OUT | |
| IN Connector | 3.5 mm TRS jack Active low external command reception (30 ms or longer ground) |
| OUT Connector | 3.5 mm TRS jack Open collector (15 V maximum voltage, 35 mA maximum current, 250 mW maximum output) |
| USB FLASH DRIVE | |
| Connector | 4-pin USB Type-A |
| Protocol | USB 2.0 HIGH SPEED (480 Mbps) |
| Device class | Mass storage |
| USB AUDIO STREAM | |
| Connector | USB Type-C |
| Protocol | USB 2.0 HIGH SPEED (480 Mbps) |
| Device class | USB audio 2.0 (USB class compliant) |
| Bluetooth® device connector | For Bluetooth adapter (AK-BT2) only |
| TUNER | |
| Frequency range | |
| DAB | Band III, 174 MHz – 240 MHz |
| FM | 87.5 - 108.0 MHz |
| Antenna connector | |
| Connector | F-type jack |
| Power | AC 100-240 V, 50/60 Hz |
| Power consumption | 14 W |
| Dimensions | 482.8 x 46.5 x 297.1 mm (W x H x D, including protrusions) |
| Weight | 2.7 kg |
| Operating temperature range | 0 - 40°C |
* 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms
Audio performance
| Frequency response | |
| 20 Hz - 20 kHz | +0.5 dB / -1.0 dB (during SD/USB playback to analog output, JEITA) |
| Distortion | 0.005% or less (during SD/USB playback to analog output, JEITA) |
| S/N ratio | 95 dB or higher (during SD/USB playback to analog output, JEITA) |
| Dynamic range | 95 dB or higher (during SD/USB playback to analog output, JEITA) |
| Channel separation | 95 dB or higher (during SD/USB playback to analog output, 1 kHz sine wave, JEITA) |
- *RoHS compliant
- *Specifications and appearance are subject to change without notice
