Mipro MTS100

Mipro MTS100 Stationary Transmitter for Tour Guide/Assistive Listening System.

Original price was: $892.00.Current price is: $725.00.

In Stock
SKU: MTS100 Category: Tag:

Description

MIPRO MTS100 Stationary Transmitter for Tour Guide/Assistive Listening System. Combo XLR/6.35mm input which can be switched between Mic/Line level. Switchable +48V Phantom Power for Mic Input. Rack mount via FB71 or two units via FB72 rack kits. Supplied with a standard rear panel antenna. Can also be used with AT70Wa Omni or AT90Wa Directional Antennas.

Features

  • Modular design for easy set-up, operation and maintenance.
  • Preset with 16 selectable channels.
  • Bright LED channel display.
  • Direct output for low level or switch to wideband amplifier for high level output.
  • Selectable input audio signal level for optimal modulation index.
  • Audio input and RF output LED indicators.
  • 48 V phantom power for condenser microphones.

Specifications

Housing EIA-standard 1/2U metal case
Display Channel in LED
Frequency Range CEPT/EU: 863 ~ 865 MHz | USA: 926 ~ 928 MHz
License-free for users in ISM bands
Modulation Digital modulation
Switching Bandwidth 2 MHz
Preset Channels 16 preset channels. At least 3 compatible channels can be used simultaneously at the same venue.
Channel Setup Manually
Stability ± 0.005%, 0℃ ~ +60℃
Channel Grid 125 kHz
RF Output Power < 10 mW (Low) | < 50 mW (High)
Antenna TNC, 50 Ω
Spurious < 250 nW @ > 1 GHz
Transmission Range > 100 meters (High setting)
Frequency Response 50 Hz ~ 10 kHz
Max AF Input Level < 15 V RMS (Line In)
Microphone Input XLR & 6.3 mm (Combo)
Input Level Switch Mic or Line-Level
Input Level Adjustment Adjustable VR
Phantom Power Switch ON / OFF
Panel Display Audio Meter, Audio Limiter, RF Hi/Low Power indicator. LED channels
Power Supply 12 ~ 15 V DC
Dimensions (W × H × D) 210 × 44 × 206 mm / 8.3 × 1.7 × 8.1 “
Net Weight Approx. 1.1 kg / 2.4 lbs
Compatible Receivers MTG-100R / MTG-100Ra
Power Supply 12 ~ 15 V DC
Note Refer to actual product in the event of product description discrepancy.
